The Fearures Of 12 Ton Rough Terrain Forklift:
Reliable and Durable: Designed with high longitudinal stability and robust construction, ensuring consistent performance and long-lasting quality.
Efficient for Tough Conditions: Optimized for use in challenging environments with low fuel consumption and no maintenance costs.
Comfortable Operation: Equipped with a multi-stage damping overall guard and suspended structure for improved driver comfort.
Clear Visibility and Comfort: The widened gantry offers good visibility, and the suspension seat enhances driving comfort.
Versatile Use: Suitable for various field operations such as mines, farmlands, and orchards.
Products parameter
| Model | Diesel |
| Rated load | 12000kg |
| Load center distance | 600mm |
| Lifting height | 3600mm |
| Mast height at maximum lift (with backrest) | Front200mm Rear250mm |
| Max. lift height | 3000mm |
| Mast lowered height | 2530mm |
| Free lift height | 150mm |
| Shelf height | 1196mm |
| Distance from the seat surface to the roof rack | 870mm |
| Overhead guard height | 2810mm |
| Length Without fork | 5030mm |
| Wheelbase | 2628 |
| Min. turning radius outside | 5800mm |
| Min. turning radius inside | 3900mm |
| Min. right angle radius width | 5900mm |
| Lowering speed (full load/no load) | 550/450 |
video
Optional Attachment
FAQ
Q: What tires does the forklift have?
A: The forklift has large, rugged tires designed to provide traction on rough and uneven surfaces.
Q: What is the fuel efficiency of the Cummins engine?
A: The Cummins engine is known for its fuel efficiency, making this forklift a cost-effective choice for industrial applications.
Q: Is visiting the factory allowed?
A: Yes, we welcome customers to visit our factory. Our factory is located in Shandong province.
Q: Can the lifting height be adjusted?
A: The forklift features a hydraulically adjustable lifting height, allowing operators to customize the lift height depending on the specific job requirements.
