Products Features
Versatile Working Heights:
The articulated growth raise affords a vast vary of working heights, from 16.6m to 40.1m, catering to a number assignment needs. This versatility ensures it can manage duties in each low and excessive elevation environments, making it appropriate for construction, maintenance, and different industrial applications.
Robust Diesel Power:
Powered by using a dependable diesel engine, this increase carry gives sturdy overall performance and prolonged operational hours. The diesel engine ensures the elevate can function in far flung or off-grid locations, handing over regular energy even in difficult job website conditions.
With a most horizontal attain of 8.5m to 21.6m, this articulated growth elevate permits employees to get entry to hard-to-reach areas with ease. The prolonged attain is best for complicated structures, making sure particular positioning and stronger productivity.
Safety And Stability:
Designed with protection in mind, the increase raise facets superior balance controls and protection mechanisms. The platform top levels from 14.6m to 38.1m, presenting impervious and steady working conditions.
Products Specifications
| MODEL | LTQD1517 | LTQD1820 | LTQD2527 | LTQD3840 | |
| DIMENSION | |||||
| Working height maximum | 16.6m | 20.1m | 26.9m | 40.1m | |
| Platform height maximum | 14.6m | 18.1m | 24.9m | 38.1m | |
| Horizontal height maximum | 8.5m | 11.7m | 16m | 21.6m | |
| Up and over clearance max. | 7.8m | 8m | 10.5m | 19.5m | |
| Length-stowed[D] | 7.7m | 9.1m | 11.28m | 14.2m | |
| Width-stowed[E] | 2.28m | 2.49m | 2.49m | 2.49m | |
| Height-stowed[C] | 2.18m | 2.67m | 2.86m | 3.17m | |
| Platform size(L×W)[A*B] | 1.53m*0.76m *1.1m |
1.83m*0.76m *1.1m |
1.83m*0.76m *1.1m |
2.44m*0.91m *1.1m |
|
| Wheel base[F] | 2.03m | 2.54m | 3.05m | 3.98m | |
| Ground clearance[G] | 0.25m | 0.41m | 0.38m | 0.43m | |
| PRODUCTIVITY | |||||
| Lift capacity | 230kg | 250kg | 230kg | 230kg/480kg | |
| Max platform occupancy | 2 | 2 | 2 | 2 | |
| Drive speed-stowed(max | 5.1km/h | 5.1km/h | 4.8km/h | 4.4km/h | |
| Drive speed-raised(max) | 1.1km/h | 1.1km/h | 1.1km/h | 1.1km/h | |
| Gradeability-stowed | 40% | 40% | 45% | 40% | |
| Turning radius-inside (stowed/raised) |
2.47m | 2.7m | 2.5m | 3.13m/3.96m | |
| Turning radius-outside (stowed/raised) |
5.18m | 5.8m | 5.98m | 6.5m/7.02m | |
| Working slope maximum | 5° | 5° | 5° | 5° | |
| Tyre | 33*12-20 | 36*14-20 | 385/65-24 | 385/65-22.5 | |
| POWER | |||||
| Power source | YANMAR | YANMAR | Cummins | Cummins | |
| Drive&steering | 4WD*2WS | 4WD*2WS | 4WD*2WS | 4WD*4WD | |
| WEIGHT | |||||
| Standard | 7800kgs | 10200kgs | 15700kgs | 24500kg | |
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
LTMG Customizations Services
FAQ
- How do you ensure timely delivery of the articulated boom lifts?
We have a robust supply chain and efficient production processes that, combined with our reliable logistics partners, ensure timely delivery of our products to any global location.
- What certifications do your articulated boom lifts have?
Our boom lifts are certified to meet international safety and quality standards, including CE, ANSI, and ISO certifications.
- Is the boom lift easy to operate?
Yes, the boom lift is designed for ease of use with intuitive controls and operator-friendly features.
- What kind of maintenance does the diesel engine require?
Regular maintenance is recommended, including oil changes, filter replacements, and inspections to ensure optimal performance.
- How does the boom lift ensure operator safety?
It is equipped with advanced stability controls and safety mechanisms to provide secure and stable working conditions.
