Product Introduction
LTMG diesel forklift Features
1. Unadorned, magnanimous, and aesthetically pleasing in appearance, with a rigorous eco-friendly design approach.
2. The expansive view door frame design broadens the driver's perspective, enhancing visibility.
3. Dependable LCD digital gauges coupled with an intuitive human-machine interface facilitate precise vehicle status control for drivers.
4. A specialized high-performance gearbox design boosts power output and elevates operational efficiency.
5. Equipped with a full hydraulic steering system, it offers a tight turning circle, agile steering, and ensures safety and reliability.
6.The elevated air intake design shields the engine from dust and maximizes engine performance effectively.
Normal attachments
1. Tobacco Clamps: specially designed for the tobacco industry, for clamping and handling tobacco packages. 11.
2. Block Clamps: for handling bricks, stones and other building materials.
3. Fork Clamps (Fork Clamps): can be used for pallet-less handling of a wide range of soft packaged goods, or regular palletized goods.
4. Tire Clamps (Tyre Handler): especially designed for tire warehouse or automobile manufacturing industry, convenient for handling tires.
5. Side Shift: Allows the forks to shift from side to side, allowing precise insertion or extraction of pallets without having to adjust the overall position of the forklift.
6. Tipping Fork (Fork Positioner): Allows the operator to adjust the fork spacing to accommodate pallets of different widths without leaving the cab.
7. Container Handling Spreader (Container Handling Spreader): Used for handling containers, including top lifting and bottom piercing methods.
Similar products
fAQ Of lTMG
1. Why choose us?
As a manufacturer, LTMG industrial is committed to offer not only products with high quality and performance and competitive price, but also in-time delivery and comprehensive 7/24 after-sale services.
2. What is the product range of our factory ?
LTMG industrial is a large-scale machinery manufacturing enterprise primarily specializes in supplying wheel loaders,skid steer loader,forklift trucks,excavator and related attachments. We can also customize non-standard products according to customer's requirements.
3. What payment terms can we accept?
Normally 30% deposit is required in advance, 70% balance shall be settled before shipment. And 100% irrevocable L/C at sight with the terms we agreed can also be accepted.
4. What Certificates do we have?
All products meet with the ISO9001 Quality System and have acquired CE certificate. EPA approval will be available if needed.
5.How about our delivery time?
Usually it will take 15 to 30 days after receiving your deposit. About standard products, we always have in stock and can deliver immediately. But customized products will take more time, depending on the requirements of your order.
6. Can we provide OEM service?
LTMG industrial can provide customized products according to customers' requirements, both OEM and ODM are acceptable.
|
Model |
FD30 |
FD35 |
FD38 |
|
|
Rated lifting load |
kg |
3000 |
3500 |
3800 |
|
Load center distance |
mm |
500 |
||
|
Free lifting height |
mm |
160 |
||
|
overall length (Withfork/Withoutfork) |
mm |
3752/2682 |
3763/2693 |
3963/2893 |
|
Width |
mm |
1225 |
||
|
Overhead guard height |
mm |
2090 |
||
|
Wheelbase |
mm |
1700 |
||
|
Minimum ground clearance |
mm |
135 |
||
|
Mast tilt angle (front/rear) |
% |
6° /12° |
||
|
Tire no. (before) |
28*9-15-14PR |
|||
|
Tire no. (after) |
6.5-10-1OPR |
|||
|
Minimum turning radius (outer side) |
mm |
2400 |
2420 |
2710 |
|
Minimum right angle aisle width |
mm |
4260 |
4260 |
4720 |
|
Fork size |
mm |
1070*125*45 |
1070*125*50 |
1070*150*50 |
|
maximum working speed(Full-load/No-load) |
km/h |
18/19 |
19/19 |
|
|
maximum lifting speed(Full-load/No-load) |
mm/s |
440/480 |
330/370 |
340/380 |
|
maximum gradeability(Full-load/No-load) |
% |
15/20 |
||
|
Forklift weight |
kg |
4250 |
4500 |
4800 |
|
Engine model |
Xinchai C490 |
|||
With technological innovation, our product configuration and parameters will continue to change without notice;
If there is any doubt, the specific confirmation of our international trade sales shall prevail;
