Technical Specification
| Model | FD100 | ||
| Power Type | Diesel | ||
| Rated Capacity | kg | 1000 | |
| Load Centre | mm | 600 | |
| Lift Height | mm | 3000 | |
| Operator type | mm | Drive in seat | |
| Max.lift height of fork(standard) | 2000 | ||
| Height of mast | mm | 2250 | |
| Free lift height | mm | 1180 | |
| Height of Load-backrest | mm | 1015 | |
| Distance from seat to overhead guard | mm | 1080 | |
| overhead guard height | mm | 2250 | |
| Length without fork) | mm | 4270 | |
| Wheel base | mm | 2800 | |
| The height of traction pin | mm | 520 | |
| Min. ground clearance | mm | 225 | |
| Overall width | mm | 2165 | |
| The distance between forks | mm | 2460/450 | |
| Tread(front /rear) | mm | 1600/1800 | |
| Min. Turning radius(outside) | mm | 4080 | |
| Min. Turning radius(inside) | mm | 210 | |
| Min. Intersecting aisle | mm | 3540 | |
| Mast tilt angle | deg | 6° / 12° | |
| Fork size | mm | 1220X175X80 | |
shipping
FAQ
Q: What Certificate do you have?
All products meet with the ISO9001 Quality System and have acquired CE certificate.
Q: Why choose us?
As a manufacturer, LTMG industrial is committed to offer not only products with high quality and performance and competitive price, such as diesel forklifts but also in-time delivery and comprehensive 7/24 after-sale services.
Q: Are you trustworthy?
With 22 years of professional manufacturing experience, we can offer you suitable suggestions and the best prices.
Q: What is the payment terms?
We accept payment via T/T, L/C, West Union, Moneygram, Paypal, and others are welcome.
