The hydraulic system of a diesel forklift truck refers to the intricate network of components and fluid lines that enable the smooth and efficient operation of various lift and movement functions. Key elements within this system work together to convert the mechanical power generated by the diesel engine into hydraulic energy, which is then utilized to control the lifting, tilting, and steering mechanisms of the forklift. Here is a detailed overview of the diesel forklift's hydraulic system :
Technical Specification
| Model | FD70 | ||
| Power Type | Diesel | ||
| Rated Capacity | kg | 7000 | |
| Load Centre | mm | 600 | |
| Lift Height | mm | 3000 | |
| Fork Size | mm | 1220×150×70 | |
| Mast Tilt Angle | 6°/12° | ||
| Fork Overhang (Wheel center to fork face) | mm | 595 | |
| Ground Clearance(Bottom of mast) | mm | 200 | |
| Length to face of fork(Without fork) | mm | 3440 | |
| Overall Width | mm | 2010 | |
| Mast Lowered Height | mm | 2500 | |
| Mast Extended Height(With backrest) | mm | 4415 | |
| Overhead Guard Height | mm | 2430 | |
| Turning Radius (outside) | mm | 3250 | |
| Travel (Full load) | Km/h | 28 | |
| Lifting (Full load) | mm/s | 430 | |
| Max.Gradeability | % | 20 | |
| Wheelbase | mm | 5800 | |
| Engine model | 6BG1-02 | ||
| No.of Cylinder | 6 | ||
| Bore×Stroke | mm | 105×125 | |
| Displacement | cc | 6494 | |
| Fuel Tank Capacity | L | 125 | |
