Products Description
Advantage
specifications
|
Model |
FD38 |
|||
|
Power Type |
Diesel |
|||
|
Rated Capacity |
kg |
3800 |
||
|
Load Centre |
mm |
500 |
||
|
Lift Height |
mm |
3000 |
||
|
Fork Size(L×W×T) |
mm |
1070×125×50 |
||
|
Mast Tilt Angle(F/R) |
Deg |
6°/12° |
||
|
Front Overhang (Wheel center to fork face) |
mm |
485 |
||
|
Ground Clearance(Bottom of mast) |
mm |
140 |
||
|
Turning Radius (outside) |
mm |
2570 |
||
|
Max.Gradeability (No load/Full load) |
% |
20 |
||
|
Wheelbase |
mm |
1800 |
||
|
Service weight |
kg |
4900 |
||
|
|
Length to face of fork(Without fork) |
mm |
2835 |
|
|
Overall Width |
mm |
1230 |
||
|
Mast Lowered Height |
mm |
2150 |
||
|
Mast Extended Height(With backrest) |
mm |
4175 |
||
|
Overhead Guard Height |
mm |
2110 |
||
|
Speed |
Travel (Full load) |
km/h |
20 |
|
|
Lifting (Full load) |
mm/s |
430 |
||
|
|
Front |
mm |
28×9-15-12PR |
|
|
Rear |
mm |
6.50-10-10PR |
||
|
Battery |
Voltage/Capacity |
V/Ah |
12/80 |
|
|
Engine |
Model |
4TNE98 |
A495BPG |
|
|
Manufacture |
YANMAR |
XINCHAI |
||
|
Rated output/r.p.m. |
kw |
43/2300 |
42/2650 |
|
|
Rated torque/r.p.m. |
N·m |
177.6-196.3/1700 |
174/1800-2000 |
|
|
No.of Cylinder |
4 |
4 |
||
|
No.of Cylinder |
mm |
98×110 |
95x105 |
|
|
Displacement |
cc |
3318 |
2980 |
|
|
Fuel Tank Capacity |
L |
70 |
70 |
|
|
|
Type |
Hydraulic |
Hydraulic |
|
|
Stage(FWD/RVS) |
1/1 |
1/1 |
||
